Descriere
FIBARO Home Center 3 Lite - Casa inteligentă începe de aici!
FIBARO Home Center, 3 Lite este versiunea mai simplă a celei mai avansate centrale inteligente de pe piață.
Suportă Z-Wave Plus v2, Wi-Fi 2,4 GHz
Single-Core ARM Cortex A7 900 MHz, RAM 512 MB, memorie FLASH 4 GB eMMC
Profiluri de uz casnic, scene avansate de automatizare, panou de alarmă, telecomandă și multe altele.
Suportă și scene LUA, max. 20 de scene
Funcționează independent sau ca Slave in legătură cu HC3
Tehnologie:
- Tehnologie de comunicare: Z-Wave Plus V2 (seria 700)
- Tehnologie de rețea: Wi-Fi 2,4 GHz
- CPU: Single-Core ARM Cortex A7 900 MHz
- Memorie RAM: 512 MB
- Memorie FLASH: 4 GB eMMC
Diferențele importante dintre Home Center 3 și Home Center 3 Lite
FIBARO Home Center 3 |
FIBARO Home Center 3 Lite |
|
Aplicații |
Aplicații versatile în automatizarea clădirilor: case, apartamente |
Case mai mici (recomandat până la 100 m2) și apartamente |
Numărul de Dispozitive Suportate |
Până la 230 de dispozitive Z-Wave |
Recomandat până la 40 de dispozitive Z-Wave |
Tehnologii de Comunicare |
Z-Wave 500 |
Z-Wave 700 |
Tehnologii de Rețea |
Ethernet, Wi-Fi 2.4GHz / 5GHz |
Wi-Fi 2.4GHz |
Procesor (CPU) |
Quad-Core ARM Cortex A53 1,2GHz |
Single-Core ARM Cortex A7 900 MHz |
Memorie RAM |
2 GB |
512 MB |
Memorie FLASH |
8 GB eMMC |
4 GB eMMC |
Posibilități de Automatizare |
LUA, scene tip bloc, panouri, programe |
LUA, scene tip bloc, panouri, programe |
Numărul Maxim de Scene |
Nelimitat |
Recomandat până la 20 de scene |
Suport Pentru Camere Ip |
Nelimitat |
1 cameră IP |
Suport Plugins și Aplicații Rapide |
Nelimitat |
5 pluginuri și 10 aplicații rapide |
Mecanismul Migrației |
Da, cu HCL, HC2, HC3L |
Nu |
Funcționare în modul portilor conexe |
Moduri MASTER & SLAVE |
Doar moduri SLAVE |
Date tehnice:
- Procesor cu un singur nucleu ARM Cortex A7 900Mhz
- Memorie de operare 512 MB DDR3L
- Hard disk 4 GB eMMC Flash
- Port USB 1 (2.0)
- Alimentare 5V DC, max. 1A (sursa de alimentare inclusă)
- Interfață de rețea WiFi
- Temperatura de funcționare 0 - 40 ° C
- Conformitatea standardelor UE RED 2014/53 / UE, RoHS 2011/65 / UE, 2015/863, IEC 62368-1: 2014
- Protocol radio Z-Wave (seria 700)
- Protocol Wi-Fi 802.11 b / g / n
- Frecvența radio 868,0-868,6 MHz, 869,7-870,0 MHz
- Frecvența Wi-Fi 2400,0-2483,5 MH
- Umiditate max. 75% umiditate relativă (fără condensare)
- Conector de alimentare USB micro B
- Dimensiuni 178 x 110 x 31mm
Cod Produs: HC3L-001 EU
FIBARO Home Center 3 Lite - Smart home starts here!
Start your adventure in FIBARO smart home with Home Center 3 Lite!
Home Center 3 Lite is a smaller version of the most advanced smart home management unit in the world. The device has been designed based on the solutions used in the Home Center 3 platform. This central unit can be connected with other Z-Wave devices which you can use while controlling electronics and household appliances, lighting, blinds, HVAC, alarm or watering system - with just a single button, gesture or word. Home Center 3 Lite is recommended for flats and smaller smart home installations.
Product highlights:
- Wireless communication using the Z-Wave 700 technology
- Efficient hardware architecture
- A solution designed for smaller building automation systems
- Quick setup
- Possibility to create automation - block scenes and LUA
- Highest data security
- Subtle design
Capabilities
The gateway is a key & necessary element of a smart home. Thanks to it, remote control and intelligent management of all devices connected to the FIBARO System is possible.
Home Center 3 Lite is the perfect way to start your adventure with a smart home.
The device at an attractive price allows you to use the full capabilities of the FIBARO system.
An attractive proposition for people who want to expand the system of Home Center 3 with additional gateways or new smaller locations (e.g. a summer house). For example hotels, big house, summer house, ...
A product complementing the HC3 offer in the area of large installations. Better price matching in large installations as a supplement to the Z-Wave network.
Home Center 3 Lite is an integral part of the FIBARO system with full support for all its elements. It is also perfect for controlling NICE group devices
Technology at the service
- Communication technology: Z-Wave Plus V2 (700 series)
- Network technology: Wi-Fi 2.4GHz
- CPU: Single-Core ARM Cortex A7 900 MHz
- RAM memory: 512 MB
- FLASH memory: 4 GB eMMC
See the most important differences between Home Center 3 and Home Center 3 Lite
FIBARO Home Center 3 | FIBARO Home Center 3 Lite | |
APPLICATION | Versatile applications in building automation: houses, flats |
Smaller houses (recommended up to 100 m2) and apartments |
NUMBER OF SUPPORTED DEVICES | Up to 230 Z-Wave devices | Recommended up to 40 Z-Wave devices |
COMMUNICATION TECHNOLOGIES | Z-Wave 500 Zigbee, BLE, NICE 433MHz / 868MHz |
Z-Wave 700 |
NETWORK TECHNOLOGIES | Ethernet, Wi-Fi 2.4GHz / 5GHz | Wi-Fi 2.4GHz |
CPU | Quad-Core ARM Cortex A53 1,2GHz | Single-Core ARM Cortex A7 900 MHz |
RAM | 2 GB | 512 MB |
FLASH MEMORY | 8 GB eMMC | 4 GB eMMC |
POSSIBILITIES OF AUTOMATION | LUA, block scenes, panels, schedules | LUA, block scenes, panels, schedules |
MAXIMUM NUMBER OF SCENES | Unlimited | Recommended up to 20 scenes |
IP CAMERAS SUPPORT | Unlimited | 1 IP camera |
PLUGINS AND QUICK APPS SUPORT | Unlimited | 5 plugins and 10 quick apps |
MIGRATION MECHANISM | Yes, with HCL, HC2, HC3L | No |
OPERATING IN CONNECTED GATEWAYS MODE | MASTER & SLAVE mode | Only SLAVE mode |
Technical data
- Processor Single-Core ARM Cortex A7 900Mhz
- Operating memory 512 MB DDR3L
- Hard drive 4 GB eMMC Flash
- USB 1 port (2.0)
- Power supply 5V DC, max. 1A (power supply included)
- Network interface WiFi
- Operating temperature 0 – 40°C
- EU standards compliance RED 2014/53/EU, RoHS 2011/65/EU, 2015/863, IEC 62368-1:2014
- Radio protocol Z-Wave (700 series)
- Wi-Fi protocol 802.11 b/g/n
- Radio frequency 868.0-868.6 MHz, 869.7-870.0 MHz
- Wi-Fi frequency 2400.0-2483.5 MH
- Operating humidity max. 75% relative humidity (non-condensing)
- Power connector USB micro B
- Dimensions 178 x 110 x 31mm
SKU: HC3L-001 EU
.
